| Parameter | SG24-C5 |
|---|---|
| Engine power(kW) | 176 |
| Overall weight(T) | 18.5 |
| Blade width(mm) | 3965 |
| External dimensions(mm) | 9445x2790x3560 |
| Engine model | WP7G240E301 |
| Fuel tank capacity(L) | 360 |
| Hydraulic oil tank capacity(L) | 110 |
| Maximum traction(kN) | 101.6 |
| Maximum forward speed(km/h) | 46.9 |
| Maximum reverse speed(km/h) | 28.5 |
| Blade cutting angle(°) | 27~73 |
| Emissions(Indicated as per international standards) | Eu stage IIIA |
