Parameter | SRD03 |
---|---|
External dimensions(mm) | 2495*1310*2000 |
Engine brand | Yanmar |
Power/speed(kW/rpm) | 26.9/3000 |
Operating weight(kg) | 2900 |
Front and Rear Static Linear Loads(N/cm) | 125/115 |
Vibration frequency low/high(Hz) | 60 |
Minimum turning radius(mm) | 2600 |
Excitation force(kN) | 30 |
Amplitude(mm) | 0.5 |
Gradeability | 0.4 |
Speed(km/h) | 0-12 |
Emissions (Indicated as per China standards) | Eu stage IIIA |
