| Parameter | DH46-C3 RS |
|---|---|
| Overall weight(kg) | 56200 |
| Engine brand | Cummins |
| Rated power/rated speed(kW/rpm) | 391/1800 |
| Machine external dimensions(mm) | 9325*4320*3990 |
| Track center distance(mm) | 2260 |
| Track shoe width(mm) | 610/660/710 |
| Ground contact length(mm) | 3532 |
| Fuel tank capacity(L) | 920 |
| Blade type | ROCK |
| Blade capacity(m³) | 13.7 |
| Emissions (Indicated as per international standards) | Eu stageⅢA |
